Whelen 600 Series Arrow Turn Signal, and Brake/Tail/Turn Light

Whelen 600 Series LED Brake/Tail/Turn Lighthead
http://www.sirennet.com/wh60btt.html
The Whelen 600 Series LED Brake/Tail/Turn Lighthead comes with 2 flash patterns including Signal-Alert pattern to enhance brake or turn signal flash activity, and dual intensity modes. When the brakes are activated, Signal-Alert provides a 4 flash burst of light in 300 millionths of a second before turning steady-on for a more eye-catching pattern. Comes standard with a newly designed gasket for mounting directly into a hole cut-out on the vehicle without using a housing or a flange. The Whelen Five Year Unconditional HDP Heavy Duty Professional Warranty applies to this lighthead.

Features:
84 High Intensity 5mm LEDs.
2 flash patterns including Signal-Alert pattern to enhance brake or turn signal flash activity.
Standard with dual intensity modes.
Replaces all min/max BTT models.
Epoxy encapsulated for vibration, moisture and corrosion resistance.
Rated for 100,000 hours of continuous operation.
Furnished with 6" four wire pigtail.
Comes standard with a newly designed gasket for mounting on the vehicle without using a housing or a flange.
Mounting flange options are purchased separately.

Specifications:
Voltage: 12 VDC.
Current Draw (Brake): 0.375 Amps.
Current Draw (Tail): 0.040 Amps.
Dimensions: 4-1/8" (105mm) H x 6-1/2" (165mm) W x 1-5/8" (41mm) D.

Certifications:
CAC, Title 13, Article 22 (red, blue and amber lightheads)
KKK 1822-E - Federal Ambulance Specification, Upper & Lower Zones.
SAE J595 - Flashing Warning Lamps for Authorized Emergency, Maintenance, and Service Vehicles (Jan 90)
NFPA 1901 - (1999 Edition).

Whelen 600 Series LED Arrow Turn Signal Lighthead
http://sirennet.com/wh60a00tar.html

The Whelen 600 Series LED Turn Signal with the Arrow shape in amber with 6 flash patterns, includes light sequencing across the arrow shape for added attention. All LED's are epoxy encapsulated to protect against shock, vibration and moisture. Rated for 100,000 hours of continuous use. Comes with Whelen Five Year Unconditional HDP Heavy Duty Professional Warranty.

Features:
6 flash patterns including light sequencing across the arrow shape for added attention.
Epoxy encapsulated for vibration, moisture and corrosion resistance.
Rated for 100,000 hours of continuous operation.
All lightheads are furnished with 6" wire pigtail
Dimensions: 4-1/8" H x 6-1/2" W x 1-3/4" D.
Mounting options are purchased separately.

Certifications:
SAE J588 - Turn Signal Lamps for Use on Motor Vehicles Less than 80" (2032mm) in Overall Width.
SAE J1395 - Turn Signal Lamps for Use on Motor Vehicles 80" (2032mm) or More in Overall Width.
