Wiring Inverters for 120/240V Split-Phase

In this video, we cover wiring the main power from two inverters into a sub-panel. Each inverter will power each side of the panel, creating 120/240V power. With this setup, you can power anything from 120V appliances to EV car charging.

I also discuss ground-neutral bonding when wiring off-grid inverters to a sub panel. It is important to understand how ground-neutral bonding works as it can create all kinds of havoc if not done correctly.

Enjoy!

   • Ground Neutral Bonding Inverters in Split ...

Check out the new EG4 6000XP (affiliate link):
https://signaturesolar.com/eg4-6000xp...

Visit my website for more details:
https://natesdiysolar.com

0:00
0:01 - Wiring the Sub Panel
3:47 - Tools and Parts
4:29 - About the Setup
6:05 - Ground Neutral Bonding
8:16 - Review
8:50 - Wiring Phase 1
13:49 - Wiring Phase 2
16:41 - Review

GND NUTARAL BOND VID1:
   • Why Do We Bond at the Service Panel and No...

GND NUTARAL BOND VID2:
   • Sub Panels Explained - Why are neutral and...
