Wiring Inverters For Grid Assist Charging / Bypass

The garage build continues! In this video I cover wiring the inverters for split phase AC input or grid assist. I'm using 2x MPP Solar LV6548 inverters in split phase. With this 50 amp circuit I will be able to charge my batteries from grid when there is not enough solar during the winter months. I will be able to charge comfortably with 6,000 watts and a max of 10,000 watts.

   • Bending Conduit - How Hard Can It Be!?

Key topics included in this video:

00:00
00:15 - Conductors
01:42 - Pull String
02:05 - The Mouse
02:48 - Pull to J-Box
03:38 - Finish Inside Run
04:07 - Pull to Service Panel
04:53 - Push Through to Inverters
06:39 - Wire the J-Box
07:48 - Wire Inverter 2P2
08:32 - Wire Inverter 2P1
09:40 - Wire Service Panel
18:03 - Test
