Fluke ScopeMeter® 120B Series Power and Harmonics Mode

http://bit.ly/2Co9Ubl

In this video we will take a look at the power and harmonics mode of the Fluke ScopeMeter® 120B series. We'll look at the included accessories, how to make sure you are ready to take measurements, and the types of data you can expect to see.

Instructions to access Power Harmonics Mode on Fluke 120B:

1. Press the MENU button
2. Use the up and down arrows to select the Power and Harmonics Mode
3. Press the ENTER button.

Additional features include:

F2 key: Toggle between histogram and waveforms

F1: Allows you to select the type of power measurement you want to record. Options include power (measured in watts), current and voltage.

For initial set up, be sure to select the right sensitivity for your probes and ensure your settings are correct for accurate measurements and analysis.

The compact ScopeMeter® 120B Series, is the rugged oscilloscope solution for industrial electrical and electro-mechanical equipment troubleshooting and maintenance applications. It’s a truly integrated test tool, with oscilloscope, multimeter and high-speed recorder in one easy-to-use instrument. The ScopeMeter 120B Series also integrates with Fluke Connect® mobile app and FlukeView® for ScopeMeter software to enable further collaboration, data analysis and archiving of critical test information.

For more information on the Fluke ScopeMeter® 120B series, visit the Fluke website here: http://bit.ly/2Co9Ubl
