Paul's Flight Deck 003 - Simple VHF Radio Part 1
Автор: The SIM Life
Загружено: 2019-01-03
Просмотров: 11661
The basic, but functional design will be the first radio I'll walk you through building. Part 1 will cover how to configure the Arduino using SimVim Configurator and we'll test it out using a few bits and the breadboard. Later I will release the "Complex" model VHF radio, but for now let's start with something easier and achievable. I'm set on keeping all of my videos under 15 minutes each but there was a lot to cover so I went over by 2 minutes.
Please check out my Site https://www.paulsflightdeck.com
1:43 IMPORTANT info about encoders in SimVim
3:35 List of steps
4:56 SimVim Configurator setup
9:20 Breadboard and Arduino Build "The fun stuff"!
15:18 Wiring Diagram for prototype exercise
15:26 Loading into X-Plane 11
15:50 Important Note about small mistake I made
16:08 Testing our radio inputs
17:10 Signoff
SimVim http://www.simvim.com
Tactile Buttons
https://www.ebay.com/itm/100Pcs-Momen...
Rotary Encoders with Push Button
https://www.ebay.com/itm/3Pcs-set-6mm...
