Jeep Grand Cherokee HID Bi-xenon projector installation headlight upgrade

Jeep Grand Cherokee, year 1997, 1998, 1999, 2000, 2001, Bi-xenon projector installation with the best XB35 bulbs available for the MH1 projectors.

𝗬𝗼𝘂 𝗰𝗮𝗻 𝗯𝘂𝘆 𝘁𝗵𝗶𝘀 𝗴𝗿𝗲𝗮𝘁 𝘂𝗽𝗴𝗿𝗮𝗱𝗲 𝗸𝗶𝘁 𝗵𝗲𝗿𝗲:
https://www.retrofitlab.com/products/...

𝗜𝗻𝘀𝘁𝗿𝘂𝗰𝘁𝗶𝗼𝗻𝘀:
0:00 Put the headlight in the carton box with heatgun for about 15 minutes and separate the glass of the housing when it's heated
0:32 Unscrew the cap what's in front of the bulb
0:42 Screw the Mini Gatlin Gun shroud on the Mini H1 bi-xenon projector with the included screws
1:09 Remove the bulb holder and nut of the projector and place the rubber ring on the tail
1:20 Loose the plug of the bi-xenon wires to get it throuth the reflector housing
1:56 The centric ring doesn't work in this headlight, so you have to align it manualy. You do need the ring for fasten the nut on the projectors tail
2:15 Screw the bulb holder back on the tail
2:33 Clean the lens and shroud before you close the headlight and add some extra butyl sealant if needed
3:21 Final view low and high beam

𝗔𝗱𝘃𝗮𝗻𝘁𝗮𝗴𝗲𝘀 𝗼𝗳 𝗮 𝗕𝗶-𝘅𝗲𝗻𝗼𝗻 𝗽𝗿𝗼𝗷𝗲𝗰𝘁𝗼𝗿 𝗿𝗲𝘁𝗿𝗼𝗳𝗶𝘁 𝗸𝗶𝘁:
• Much better light output
• No glare
• Lower energy consumption (35 watt instead of 55 watt)
• Luxury OEM look

𝗧𝗵𝗶𝘀 𝗸𝗶𝘁 𝘄𝗶𝗹𝗹 𝗳𝗶𝘁 𝗼𝗻:
• Jeep Grand Cherokee (1997 - 2001)

𝗖𝗵𝗲𝗰𝗸 𝗼𝘂𝘁 𝗼𝘂𝗿 𝗻𝗲𝘄 𝗙𝗮𝗰𝗲𝗯𝗼𝗼𝗸 𝗴𝗿𝗼𝘂𝗽:
  / europeanheadlightcommunity

𝗙𝗶𝗻𝗱 𝘂𝘀 𝗼𝗻:
Facebook:   / retrofitlab
Messenger: https://www.m.me/Retrofitlab/
Instagram:   / retrofitlab.com_official
Our website: https://www.retrofitlab.com/

𝗢𝘂𝗿 𝗦𝘁𝗼𝗿𝘆:
Retrofitting refers to the addition of new technology or features to older systems. These days there are a lot of people who put a simple plug & play xenon kit in their halogen headlight housing in an attempt to improve night vision and looks of their vehicle. In fact they don’t realize that their headlight beams are often worse than before. Night vision achieves relatively little improvement on night vision because of a poor beam pattern, which increases the blinding of other road users. This is because their headlight housings are designed for halogen and not xenon.

A true Bi-Xenon projector update is now possible for your car. Such an upgrade will significantly improve your light output from 700-2100 lumens to 2800 and 3500 lumens, without blinding other traffic with glare from your headlight. Upgrade your headlight OEM style!

The latest high power Led bulbs will upgrade both the exterior and interior lighting system of your car. Led lighting is becoming more and more popular in the automotive market for obvious reasons. They have longer lifetime, use less energy and improve safety with their fast response time.

Do you have any questions? Do not hesitate to contact us, we are happy to help you out!

Good luck with your retrofit!

These products are not ECE-approved and must not be used on public roads in any exterior application. Use on public roads will invalidate both the operating license and insurance coverage.
