Honda ATC 200x Build - Part 16 - Motor Engine Bottom End Clutch, Cover, Lifter Arm, Oil Filter Rotor

Honda ATC 200x Build - Part 16 - Assembly (videos coming fast so subscribe to keep notified). Part 15 completion, sealing up the clutch cover with a new gasket and some waterproof grease and then torqueing the right crankcase cover bolts. First we will be installing the clutch outer guide, clutch basket (clutch outer), pressure plate, clutch fibers (clutch discs), clutch plates, clutch lifter plate, clutch springs, clutch lifter bearing, oil filter rotor, primary drive gear, oil drain plug, oil dipstick, decompressor cam follower shaft assembly, crankcase cover oil seals. Then we will be replacing and torqueing (torque) to spec all of the lock nuts, bolts, thrust washers, collars, bushings, adjusters, springs, seals, and crush washers, circlips, snap rings (snaprings), clamps, brackets, and rubber grommets. The engine cases were chemically stripped of all the black paint by Xpress Metal Cleaning and then vapor blasted by Vapor Blasting by Design LLC here in Phoenix, AZ. This is an atv trike 3-wheeler restoration rebuild.

0:00 - Upcoming Build Progress
2:41 - Gas Tank Video Preview
5:09 - Clutch Installation
19:26 - Oil Filter Rotor
27:33 - Right (Clutch) Crankcase Cover Assembly
37:54 - Kick Starter Ratchet, Clutch Bearing
41:05 - Right Crankcase Cover Installation
43:32 - Clutch Cover Bolts Torqued

Motor (Engine) Bottom End
Right Crankcase Cover (Clutch Cover)
Crankcase Cover Gasket
Clutch Outer Guide
Clutch Basket (Clutch Outer)
Clutch Springs
Pressure Plate
Clutch Center
Clutch Plates
Clutch Fibers (Clutch Discs)
Clutch Lifter
Clutch Lifter Bearing
Primary Drive Gear
Oil Filter Rotor
Oil Filter Rotor Cover
Decompressor Cam Follower Shaft Assembly
Kick Shaft Cam
Kick Shaft Cam Reset Spring
Kick Shaft Cam Reset Spring Seat
Oil Seals
Gaskets
Lock Nuts
Thrust Washers
Collars
O-Rings
Springs
Collars
Oil Seals
Bushings
OEM Bracket
