Honda ATC 200x Build - Part 15 - Motor Engine Bottom End Kick Starter, Shifter, Oil Pump, Cam Chain

Honda ATC 200x Build - Part 15 - Assembly (videos coming fast so subscribe to keep notified). In this video we will be sealing the crankcase halves with a new gasket and some waterproof grease and then torque the crankcase bolts. We will also be installing the timing chain (cam chain), cam chain guide (timing chain guide), return spring pin, shift linkage, shift star, gearshift plate, gearshift guide plate, shift drum stopper, shift shaft (gearshift spindle), kick stop plate, kick starter (kickstarter, kicker), oil pump, oil pump chain, oil pump drive gear, oil pump driven gear, oil pump cover plate. Then we will be replacing and torqueing (torque) to spec all of the nuts, bolts, thrust washers, collars, bushings, adjusters, springs, seals, and crush washers, circlips, snap rings, clamps, brackets, and rubber grommets. The engine cases were chemically stripped of all the black paint by Xpress Metal Cleaning and then vapor blasted by Vapor Blasting by Design LLC. This is an ATV trike 3-wheeler rebuild.

0:00 - VERY Short Intro
0:53 - Crankcase Gasket
5:36 - Seal Crankcase Halves
6:42 - Crankcase Bolts
14:53 - Return Spring Pin
16:12 - Timing Chain & Guide
17:57 - Shift Linkage
24:24 - Kick Starter Assembly
32:53 - Kick Starter Install
37:49 - Oil Pump Assemble
39:50 - Oil Pump Installation
44:00 - Clutch Install Teaser
45:22 - Outro Next Video Details

Motor (Engine) Bottom End
Crankcase (Crank Case) Sealed
Crankcase Gasket
Left Crank Case
Right Crank Case
Return Spring Pin
Timing Chain (Cam Chain)
Timing Chain Guide (Cam Chain Guide)
Shift Linkage
Shift Star
Shift Drum Stopper
Kick Starter (Kickstarter, Kicker)
Kick Start Gear
Kick Starter Ratchet
Oil Pump
Oil Pump Chain
Oil Pump Drive Gear
Oil Pump Driven Gear
Oil Pump Cover
Oil Bushings
Collars
O-Rings
Springs
Collars
Oil Seals
Bushings
OEM Bracket
