Honda ATC 200x Build - Part 14 - Motor Engine Bottom End Crankcase Bearing, Crankshaft, Transmission

Honda ATC 200x Build - Part 14 - Assembly (videos coming fast so subscribe to keep notified). In this video we will be installing the crankcase bearings and crankshaft (crank) using the heat (oven) and cold (freezer) method. We will also install the oil seals, bearing retainer plate (red loctite thread locker), and will be disassembling, cleaning, and reassembling the transmission main shaft gears, collars, lock washers, and oil bushings. We will then install the shift forks, shift drum, and shift fork shaft into the left crankcase. Then we will be replacing and torqueing (torque) to spec all of the nuts, bolts, adjusters, springs, seals, and crush washers, circlips, snap rings, clamps, brackets, and rubber grommets. The engine cases were chemically stripped of all the black paint by Xpress Metal Cleaning and then vapor blasted by Vapor Blasting by Design LLC. This is an atv trike 3-wheeler rebuild.

0:00 - Short Intro
3:03 - Crankcase Bearings
14:42 - Bearing Plate & Oil Seals
20:04 - Transmission Disassembly
28:34 - Transmission Assembly
46:46 - Transmission Install
50:22 - Install Shift Forks
51:42 - Insert Shift Drum
53:27 - Shift Forks Shaft
56:23 - Outro TRX200SX Bottom End Differences

Motor (Engine) Bottom End
Crankcase (Crank Case) Bearings
Left Crank Case
Right Crank Case
Crankshaft (Crank Shaft)
Oil Seals
Bearing Retainer Plate (Bearing Holder Plate)
Transmission Main Shaft
Transmission Countershaft (Counter Shaft)
Gears
Oil Bushings
Shift Forks
Shift Drum
Shift Forks Shaft
O-Rings
Springs
Collars
Dust Seal
Bushings
OEM Bracket
