2009 Eastern Bikes Grim Reaper New School BMX Freestyle Flatland Bike Bicycle

This is a 2009 Eastern Bikes Grim Reaper New School BMX Freestyle Flatland Bike Bicycle from the late 2000's.

The 2009 Eastern Bikes Grim Reaper was a popular BMX bicycle known for its focus on being lightweight and having a distinctive look. It was Eastern's top-tier frame at the time, designed for professional-level riders.

Here's a breakdown of its key features and characteristics:

Frame:

Material: Full Chromoly, known for its strength and relatively light weight.

Helix Downtube, Toptube & Chainstays: This was a notable feature, incorporating internal ribs within the tubing to help prevent denting and improve the strength-to-weight ratio.

E3 Welding Process: Eastern touted this process for ensuring dependable frame construction.

"EB" Cutouts: A classic Eastern Bikes design element, the Grim Reaper often featured cutouts in the head tube (sometimes an "EB" logo, sometimes two vertical slots in earlier versions) and reinforced cutouts in the seat tube and bottom bracket. This was done to save weight and give the bike a unique aesthetic.

Integrated Seat Clamp: Allowed for a lower seat position and a cleaner look.

Removable Gyro Tabs and Cable Guides: Offering versatility for riders who preferred to run a detangler or a clean, brakeless setup.

Mid Bottom Bracket (BB): A common standard for BMX bikes, offering a sturdy and reliable crank setup.

Integrated Headset: For a clean front end and easy maintenance.

Heat-Treated Components: Including the wide Mid bottom bracket and CNC'd 8mm thick dropouts, for increased durability.

Spy Clamp: An integrated seatpost clamp within the frame, adding to the sleek design.

Sizes: Typically available in various top tube lengths, such as 20.5", 20.75", and 21".

Geometry:

Head Tube Angle: Around 75° (for quick steering)

Seat Tube Angle: Around 71°

Chain Stay Length: Around 13.5" (or 13.2" slammed, indicating a short rear end for responsive maneuvers)

BB Height: Around 11.5"

Standover Height: Around 8.7"

Weight: The frame itself was notably light, around 4.75 lbs.

Components (on a complete 2009 Grim Reaper):

While component specs could vary slightly, a typical complete 2009 Grim Reaper would likely include:

Fork: Full Chromoly with a 1-piece steerer tube.

Bars: Full Chromoly, often with 9.0" rise.

Crankset: 3-piece, 48-spline chromoly cranks (e.g., Eastern Throttle Cranks).

Sprocket: Alloy (e.g., Eastern Phorcys).

Wheels: Double-wall rims for durability, typically laced to fully sealed hubs.

Tires: Eastern Squealer 100psi tires (often 2.4" wide).

Pedals: Eastern Facet pedals.

Seat: Pivotal seat and post.

Pegs: Often came with steel pegs.

Brakes: U-brake, often with a forged alloy lever (though many riders would remove them for a brakeless setup).

Overall Impression:

The 2009 Eastern Grim Reaper was marketed as a lightweight, professional-level BMX bike built for performance. While its aggressive weight-saving features were innovative, some riders experienced frame cracking, particularly in earlier iterations or if they were heavier riders. However, it was generally well-regarded for its responsive geometry, sleek appearance, and a good balance of strength for typical freestyle riding. It had a distinctive "coolant gold" color option that was quite memorable.
