Uncut footage of a mountain climb, ridge surfing, couple of dives and then back home. I solved the vibration issue on the Chimera 7 LR, in the end there was an unbalanced motor, simply replacing it solved the problem.
9.3 Km total travel distance, 11:25 flight time, 3.000 mah used from the 6s2p 21700 samsung-40t 8.000 mah li-ion battery pack.
Video feed is from the Gopro Hero 5 Black.
The video overlay was made using Dashware, joining the logs from the goggles and the opentx telemetry. Credits to Drone racing Hungary:
( https://droneracehungary.hu/dji-srt-t... ) and Snappy FPV ( • Tutorial: OpenTX Logs in Dashware | Teleme... ) for their tools.
See my tutorial video on how to make this overlay : • Dahsware - How to integrate DJI SRT & Tel...
Antennas used on goggles :
2x prodrone.pl helical 12 turn 14 db ( https://shop.prodrone.pl/pl/p/PRO-Hel... )
Truerc 5.8ghz Sniper II 13.5 DBi ( https://www.truerc.ca/shop/5-8ghz-2/r... )
VAS Pepperbox Extreme 13.25 Db ( https://www.videoaerialsystems.com/co... )
Images of my gear (goggles, drone, radio) : https://onedrive.live.com/?id=4E7DDD4...
Drone : Chimera 7 LR ( https://shop.iflight-rc.com/index.php... )
Weight all-out in this test was 1.400 grams.
Motors : 4x T-motor F90 1.300kv long range ( https://www.banggood.com/T-MOTOR-F90-...)
Props : Gemfan flash 7040x3 ( https://it.banggood.com/2-Pairs-Gemfa... ).
ESC : Rush Blade Super 60A 96Hz, timings 23 ( https://it.aliexpress.com/item/100500... )
FC : Mamba F722S blutooth ( https://www.diatone.us/products/mamba... )
Battery : 6s Li-On 6s2p 8.000Mah, 21700 Samsung INR-40T cells ( https://www.farinsframes.com/6s-8000m... )
BN-220 GPS ( https://it.banggood.com/Beitian-Dual-... ).
Radio : Radiomaster TX16S ( https://it.banggood.com/RadioMaster-T... )
JR Module : TBS Crossfire TX lite ( https://www.team-blacksheep.com/produ... set to 2W
Radio antenna : TBS shapeshifter ( https://www.team-blacksheep.com/produ... ) , set in vertical position and in directional mode.
Receiver : TBS crossfire diversity nano rx ( https://www.team-blacksheep.com/produ... ) set at 8CH. Dynamic power set to off, because i want it to always work at the output power that i select in the radio.
RC Link antennas : 2 x Truerc planar bazooka dipole 868mhz antennas vertically placed, one at the front and one at the back ( https://www.truerc.ca/shop/linear-ant... ) set at 20 degrees
Video antennas : 2x tbs triumph pro mmcx, directly attacched to the Air unit with a self made 3d stand (long range) ( https://www.team-blacksheep.com/produ... ).
Dji unit settings : 1.200mw, 50 mbit, High Quality, 4/3 screen, autofocus off, power control on
Betaflight main settings : 4.2.9 firmware
Pids : Roll – 28,72,58,106. Pitch : 54,95,76,113. Yaw : 68,90,10,107.
Filters : 1.8 / 1.3 Gyro rpm : 3 / 100. Dynamic notch ; 0 – 250 – 100 – 350
Pids & Filters tuned with Plasmatree PIDS analyzer : https://www.getfpv.com/learn/fpv-in-d...
