AOS Falcon 7 - Long Range Digital FPV - Mountain Crest Proximity Cruising & Diving

In this video I take a tour of 14 Km, 14 minutes flight time, with the 6s2p 21700-P42 8'400 mAh molicel Li-ion battery pack. I tried some mountain top proximity (for my standards at least) passages, and a few dives down to the valley.

I used 4.000mah in the flight, which means I could have made this trip twice with the same battery.

This time I forgot to set the DJI air unit power level back to 1.200mw, so I started the flight with 25mw. Because of that I had to turn back right away, hover for a sec, set the power level to 1200 and then restart the climb. ALWAYS CHECK THE CROSSFIRE AND AIR UNIT POWER LEVEL BEFORE ANY FLIGHT!

Video footage is from a Gopro Hero 6 with firmware 1.6.
Resolution: 4k 4:3 30 fps
Wide FOV
Protune On
ISO min 100, ISO max 400,
Shutter auto
Gopro color
Medium Sharpness
Auto WB
The GoPro video segments were joined with Reelsteady joiner: https://github.com/rubegartor/ReelSte...
and then smoothed with Reelsteady GO ( https://www.reelsteady.com/pages/go-d... ), Smoothness 2 ticks to the left from the center, pan speed all the way to the right. The video overlay was made using Dashware. Credits to Drone racing Hungary ( https://droneracehungary.hu/dji-srt-t... ) and Snappy FPV (    • Tutorial: OpenTX Logs in Dashware | Teleme...  ) for their tools. See my tutorial video on how to make this overlay:    • Dahsware - How to integrate DJI SRT &  Tel...

Images of my gear and stuff: https://onedrive.live.com/?id=4E7DDD4...

Antennas used on goggles:
2x prodrone.pl helical 12 turn 14 db ( https://shop.prodrone.pl/pl/p/PRO-Hel... )
2x Mike Malagoli 6-turn helicals custom made & tuned for the 2nd channel of the dji goggles ( https://ko-fi.com/s/25395edd9f )

Frame: AOS Falcon 7" ( https://www.cncdrones.com/falcon-7-ci... ).

All up weight in this test was 1.622 grams.

Motors: 4x Racerstar AirA 2508 BP 1.200kv long range. They are decent for their price, but definitly undersized for this build. You need 2806.5 or 2810 motors to properly drive 1.600 grams of drone. I'll see what I can do next time.

Props: HQProp 7040x3 ( https://www.hqprop.com/hq-durable-pro... )
ESC : Rush Blade Super 60A 48Hz ( https://it.aliexpress.com/item/100500... )
FC : Mamba F722S blutooth ( https://www.diatone.us/products/mamba... )

Battery: 6s Li-On 6s2p 8.400Mah, 21700 Molicel P42 cells ( https://www.farinsframes.com/6s-8000m... )

BN-220 GPS ( https://it.banggood.com/Beitian-Dual-... ).

Vifly finder 2 active Buzzer ( https://www.viflydrone.com/viflybuzze... ).

Radio: Radiomaster TX16S ( https://it.banggood.com/RadioMaster-T... )

JR Module: TBS Crossfire TX lite ( https://www.team-blacksheep.com/produ... )

Radio antenna: TBS shapeshifter ( https://www.team-blacksheep.com/produ... ) , set in vertical position to cope with the bardpole

Receiver: TBS crossfire nano rx ( https://www.team-blacksheep.com/produ... ) set at 8CH. Dynamic power set to off, because i want it to always work at the output power that i select in the radio.

RC Link antennas: 1 x Truerc planar bazooka dipole 868mhz antennas vertically placed at the rear at 20° degrees ( https://www.truerc.ca/shop/linear-ant... )

Video antennas: 2x tbs triumph pro (long range) ( https://www.team-blacksheep.com/produ... ).

Dji unit settings: 1.200mw, 50 mbit, High Quality, 16/9 aspect ratio, autofocus off, power control on

Betaflight main settings : (4.2.9 firmware)
Thrust_linear = 25
Pidsum_limit = 1000
Pidsum_limit_yaw = 1000

PIDs
Roll 67 95 57 45
Pitch 74 100 62 48
Yaw 72 95 0 45
Feedforward 1.0

Filters
Gyro: Only lowpass filter 1, set at 150hz PT1

RPM filters: 3 / 85
Dynamic notch filters : 0 250 100 400

D-term:
Cutoff lowpass 1 : 85hz / biquad, all the rest turned off
Yaw lowpass cutoff : 80hz

ESC settings: PWM 48 Hz, timings 23

0:00 Take off
0:50 Forgot to set proper DJI Air unit power output so I did it mid flight
1:14 Back to the climb
4:30 Riding the crest
5:50 First Dive
6:11 Almost hit power cables
6:20 Towards second cliff
7:56 Second Dive (small)
8:20 Back towards the top
11:49 Last Dive
13:00 Over the city of Barzio
13:17 Landing approach
