Lecture 6 |Design Automation Using Keysight ADS | Constant Gain Circle EXAMPLE

Learn Verilog with Practice : https://www.whyrd.in/s/store Design Automation Using Keysight ADS, this video explained the automation power of ADS in microwave amplifier design and we simulated the example we have taken in lecture 4.Finally we have simulated microwave amplifier using keysight ADS, other things we will learn are, how to use smith chart tool in ADS, how to draw gain circles in ADS smith chart tool. We also answered that, During determining matching circuit, why we need to conjugate our Zs value and a simulation proof that indeed each point on constant gain circle result in a constant gain

In our previous video on this playlist of channel whyRD, we have already explained the concept of the Constant Gain circle and calculated the required value for simulation, constant gain circles are used mostly in unilateral amplifier design for a less than maximum power gain requirement as for maximum gain we can easily do conjugate matching. here we assumed our device unconditionally stable.We used microwave amplifier design by Gonzalez as our reference
