HobbyKing RX3S OrangeRX 3-Axis Flight Stabilizer V2 (V-tail/Delta/AUX) Part 2

Part 2 Review of HobbyKing RX3S OrangeRX 3-Axis Flight Stabilizer V2.
This version now has the ability to be switched on/off remotely from your RC transmitter.
I also has two exta configurations for V-tail and Delta Wing(Elevons).
LED will flash if you have the V-Tail or Delta mode switches ON/Reversed.
For V-Tail, the two servos for it are normally put in the rudder and elevator sockets.
For Delta, the two servos for it are normally put in the aileron and elevator sockets.
For Flaps or Flaperons see workaround below:

Work around for Adding Flaps posted by TechKnow in HK discussion:
"The TRUE best answer for useing this with 2 aileron servos with mixed in flaps/spoilers is to buy 2 TURNIGY V-Tail Mixer's and add them out of each of the L-ail and R-ail output of the stabilizer and use TURNIGY V-Tail Mixer to mix in separate non mixed raw flap chanel from RX with a Y adapter cable each of the Y output cable to each of the other input of the 2 TURNIGY V-Tail Mixers and set servo reversing as needed. Each V-tail mixer is only $3. And useing 2 v-tail mixers is smaller and lighter and cheaper than buying a second stabilizer just to use only its aileron output. Or useing one stabilizer and only stabilize one aileron. With my way you will have both ailerons stabilizing airplane with flaps/spoilers , not just one."

All Needed parts for this flap mod is...
1 RX3S OrangeRX 3-Axis Flight Stabilizer V2 (HK 28456)
2 TURNIGY V-Tail Mixers (HK 6321)
1 servo Y cable.

Flight stabilizer:
http://www.hobbyking.com/hobbyking/st...

Part 3 can be found here:
   • HK RX3S 3-Axis Gyro V2 (Part 3) and Up Ele...

Manual for V3 (No V2 Manual yet).
http://www.hobbyking.com/hobbyking/st...

For information on V3 see this video:
   • HobbyKing RX3S OrangeRX 3-Axis Flight Stab...
