Atari Simple XE Video output mod

🛍️ Lectronz store: https://lectronz.com/stores/theretroc...
. A super simple s-video mod for the Atari 65XE and 130XE - S.X.E video!


🛠 Tools and kit:   / tools-and-kit-77570017
💬 Discord:   / discord
😎 Ad-free, early access:   / theretrochannel

Replace R204 with a 68ohm 1/4W resistor
Replace R205 with an 820ohm 1/4W resistor
Bridge/jump R116
Add a short 24AWG or larger wire from pin 8 or 9 of the 4050 (U20) to a ground point near the RF modulator

🔗
Atari Control Picture ACP program: https://atariage.com/forums/applicati...
Drunk Chessboard Demo: https://a8.fandal.cz/detail.php?files...
🔗

🎞
0:00 Intro
1:23 The setup
2:45 Stock video output
4:08 First circuit change
7:42 Result from first change
8:49 Second change
10:21 Second result
14:28 Third change
15:53 Third result
18:09 Fourth change
21:28 Fourth and final result
22:06 Fixing the supervideo mod
22:52 Summary of changes
23:27 Outro
24:44 Drunk again?
🎞

Thanks for watching!

#AtariSXEvideo #atari65xe #atari8bit
