EL34 Push Pull Amplifier; How to Calculate Output Transformer, (Examples)
Автор: EL34_eRke
Загружено: 2024-02-08
Просмотров: 3519
Описание:
A Serial of several short Video Documents will describe Simple, Practical Design Procedure for Push Pull Amplifier based on EL34 tube.
It will be addressed:
Output Transformer, Zpp Selection and Transformer Calculation
Choke (Inductor) Design and Calculation
Power Tube Biasing
Power Tube Limits Analyzing
DC Coupled Pre Amp & Phase Splitter; Differential Driver; Design, Biasing and Gain Calculation
Grounding Connection for Hum Suppression
Chapters:
0:00 Intro
0:47 Example 1
2:00 Example 2
2:51 Example 3
3:48 Example 4
4:03 Appendic
6:08 Bonus; Mile Nestorovic
6:28 Project Related Doc.
