Building a Self-Driving Go Kart

I made a self-driving go kart by utilizing a machine learning technique called behavioral cloning.

Please consider supporting my projects on Patreon:   / austinblake

The go kart (AKA the Teskart) is equipped with 3 Logitech C920 webcams. All three cameras are used during data collection and only the middle one is used when self-driving. It provides the necessary visual input for the model to analyze and make steering decisions.

The steering motor is from a power wheelchair. The wheelchair motor functions as a giant servo motor which is controlled by an Arduino and a Cytron DC motor driver. Position feedback is achieved through a potentiometer that rotates along with the motor shaft. The Arduino reads the potentiometer value and PWM signal, and uses a PID controller to compute and provide the appropriate output.

A second Arduino is used to receive the predicted steering angle data from Python though serial communication and convert it into a PWM signal to be sent to the first Arduino.

An onboard laptop serves as the brains behind the operation and is used for recording data, training the model, and evaluating its performance.
