Lecture 17: Inverters, Part 1

MIT 6.622 Power Electronics, Spring 2023
Instructor: David Perreault

View the complete course (or resource): https://ocw.mit.edu/courses/6-622-pow...
YouTube Playlist:    • MIT 6.622 Power Electronics, Spring 2023

This lecture starts with a review of the Fourier Series and waveform characteristics in the time and frequency domains, including the decomposition of waveforms into odd and even components and half-wave symmetric and half-wave repeating components. The single-phase full-bridge inverter (dc-to-ac converter) is introduced along with simple techniques to control the AC output.

License: Creative Commons BY-NC-SA
