Mini & Special Structure | Teardown of AOHi 100W Mini GaN Charger (Dual Ports)
Автор: ChargerLAB
Загружено: 2021-11-19
Просмотров: 10604
You can buy it on Amazon: https://amzn.to/3q6i1Cp
If you wanna buy the tester of POWER-Z, you can visit our Amazon store:
https://www.amazon.com/s?me=A31UM8SRX...
Introduction
---------------------------------------------------------------
Hi, guys. This is ChargerLAB.
Today, we will tear down a 100W dual USB-C GaN charger from AOHi.
It belongs to the Magcube series.
There are also 30W and 65W Magcube chargers on sale.
Both USB-C can support 100W output.
And it can support 65W and 30W when you charge two devices.
Bill of materials (BOM)
------------------------------------------
PFC Boost Controller: NXP
PFC Boost Switch Transistor: ON Semiconductor
Electrolytic Capacitors: AiSHi
Capacitor of Master Control Chip: TEAPO
Master Control Chip: PI INN3379C
Synchronous Rectifier MOSFET: AOS AONS62922
Bridge Rectifier: Yangjie Technology
Output Filtering Capacitors: BERYL Electronics
SMD Y Capacitor: TRX
Protocol Chip: Injoinic IP2726
MOSFET: Vanguard VS3610AE
Chapter
----------------------------------
0:00 Intro
0:21 Unboxing
1:14 Testing
2:58 Teardown - Start
4:39 Teardown - Analysis
8:11 Summary
