Introduction
---------------------------------------------------------------
In recent years, more and more manufacturers have launched many different ultra-thin GaN chargers, including realme, TEGIC, and Baseus. ChargerLAB also recently got an ultra-thin 65W GaN charger from AOHi.
Today, we will take apart it to see its internal structure and how it is made so thin.

Bill of materials (BOM)
------------------------------------------
Input Fuse: Betterfuse
X2 Safety Capacitor: WQC
Bridge Rectifier: PANJIT RPMS410
Electrolytic Capacitor: Beryl
Master Control Chip (GaN IC): Silergy
Planar Transformer: Techigh
SMD Y Capacitor: ISND
Optocoupler: Everlight EL1019
Synchronous Rectifier Controller: Silergy SY5238
Synchronous Rectifier: AOS AONS66947
Solid Capacitor: Beryl
Protocol Chip: Injoinic IP2736U
VBUS MOSFET: Vergiga Semi VS3618BE
USB-C Connector: CZT

Chapter
----------------------------------
0:00 Intro
2:14 Test
3:02 Teardown
3:48 Analysis
6:41 Summary
