How To Remove Chrysler 200 Radio 📻 FAST

Quickly and easily replace or upgrade your Chrysler 200 📻 radio in less than 3 minutes ⏲️. Please 👍 & 🔔 if this helps! Click on SHOW MORE for a step by step guide 📋 with all tools used. 👉👉👉



Very few tools 🧰 to gather:

👉
Ratchet Wrench 3/8" https://amzn.to/2JiEG9d
OR
Power Tool https://amzn.to/35VxnvN

👉
Torx T15 bit https://amzn.to/3d89N2J
OR
Torx bit ratchet wrench set https://amzn.to/3hIs8GN

👉
Flat Tip Screwdriver https://amzn.to/3wbHuZd

👉
Pliers https://amzn.to/35WmFVV




REMOVAL INSTRUCTIONS:


Step 1: Pry around the edge of the bezel using a flat trim like stick or screwdriver. Then lightly pull it out.


Step 2: Unclip the wire connector that connects on the lower portion of the bezel and that specifically connects to the flashing lights and traction control buttons.


Step 3: Remove the 🕛 clock connector near the top of the bezel.


Step 4: The bezel is now free to remove completely.


Step 5: Use a T15 bit with either a power tool (preferred) or a ratchet wrench to remove the 4 screws that hold the radio into place. Then pull out the radio lightly and let it lay on the gear shift.


Step 6: Remove each of the 5 unique connectors that plug into the back of the radio 📻. If having difficulty removing some of the connectors then use a pliers.

ℹ️ Remember to squeeze the tab of each connector when removing.


Step 7: Pull out the unit.




INSTALL:



Step 8: Plug each connector back into the radio, and then push the radio back into its slot.


Step 9: Using a T15 bit, screw each of the 4 screws back into place.


Step 10: Plug the clock connector in to the back of the bezel.


Step 11: Connect the other 2 connectors towards the bottom of the bezel into place.


Step 12: Tap the bezel edges in with your fist all around, so it snaps into place.
