SITECH Intermountain Trimble Earthworks Infield Design Alignment and Section

This video shows how to create an infield design using Trimble Earthworks machine control software. The first step is to create an alignment by walking the excavator along the path the drain is to take and positioning each change in alignment with the focus point on the bucket. Once the alignment is created, a section can be created by specifying the width and shape of the drain. The section can then be used to guide the excavator as it digs the drain.

Here are the steps on how to create an infield design using Trimble Earthworks:

1. Open Trimble Earthworks and select the "Infield Design" mode.
2. Click on the "Create" button and select "Alignment".
3. Walk the excavator along the path the drain is to take and position each change in alignment with the focus point on the bucket.
4. Once the alignment is complete, click on the "Create" button and select "Section".
5. Specify the width and shape of the drain and click on the "Create" button.
6. The section will now be displayed on the screen.
7. Use the excavator to dig the drain along the section.

Here are some tips for creating an infield design:

Use the focus point on the bucket to accurately position the alignment.
Make sure the alignment is smooth and free of sharp turns.
Specify the width and shape of the drain carefully.
Use the section to guide the excavator as it digs the drain.

Here are some benefits of using Trimble Earthworks for infield design:

Increased accuracy
Improved productivity
Reduced risk of accidents
Increased profitability

Trimble Earthworks is a powerful machine control software that can help you improve your infield design projects.
