Part 3 - Honda CRV 2.0 K20 A4 Head Gasket Repair. Timing Chain episode.

This is Part 3 of the 10 videos in this series of replacing the Head Gasket. There are 13 videos in total on the Honda CRV. This episode takes you to removing timing chain inc Pulley Bolt.
PART 4 CLICK HERE ➡    • Part 4 - Honda CRV 2 litre K20 A4 Head Gas...   ⬅
⬇️💥⬇️ Links Below & Donations ⬇️💥⬇️ minutes in.

In Part 1 I did a lot of the initial basic work and ended with the removal of the Plastic Outer Intake manifold.
In Part 2 I get to the point of removing the Cylinder Head Cover.
In this Part 3 I get to the stage of removing the timing chain.

⚡Useful Tools Some Used In This Video
1️⃣ 19mm weighted socket & 50mm🕔 04:13 🚧 https://amzn.to/3qApAll 🚧
2️⃣ Budget 50MM Crankshaft Pulley Wrench 🕔 04:13 🚧 https://amzn.to/3bcq2Lf 🚧
3️⃣ Sealey Axle Stands 🕔 04:13 🚧 https://amzn.to/37eAGjq 🚧
4️⃣ 🕔 04:38 🚧 Koken 6749-1000 3/4" DRIVE RATCHET 1000 LONG (around £150) 🚧
4️⃣ Link for Koken 🚧 https://www.uktools.com/34-drive-ratc... 🚧
5️⃣ Dewalt High Torque Impact Wrench🕔 04:55 🚧 https://amzn.to/2N0pvnD 🚧
6️⃣ Sealey Extendable Ratchet 🕔 05:09 🚧 https://amzn.to/3paDunP 🚧
7️⃣ Sealey Breaker Bar, 3/4" 1000mm 🕔 04:38 🚧 https://amzn.to/3rX91eI 🚧
8️⃣ Rothenberger Quick Fire Torch 🕔 05:47 🚧 https://amzn.to/3scLIxz 🚧
9️⃣ Dewalt LED Torch 🕔 06:10 ​ 🚧 https://amzn.to/2LTf1FZ​ 🚧
🔟 Coats & Gaiters Recommended 🚧 https://www.amazon.co.uk/shop/coatsan... 🚧

⚡Coats and Gaiters is a participant of the Amazon Influencer Program.
https://www.amazon.co.uk/shop/coatsan...
I may earn a small commission with my affiliate links, though the prices paid are no higher but they do help me fund this channel.

⬇️Timecodes
00:00 Introduction
00:41 Bring Engine to TDC on Compression Stroke
01:52 Could be on Compression or Exhaust stroke
03:22 Remove the Infamous 19mm Crankshaft Pulley Bolt
07:00 The BOLT IS OUT !!!
07:29 Remove Crankshaft Pulley
08:48 Remove iVTEC Solenoid Valve
12:40 Remove Engine Mount next to Timing Chain
15:11 Remove Engine Bracket
17:11 Remove VTC Solenoid Valve
18:20 Remove Timing Chain Cover
21:39 Remove the Timing Chain
23:40 Remove the Tensioner
25:58 Remove the Front Chain Guide
26:58 Remove the Rear Chain Guide
27:44 Remove Crankshaft Position Sensor
28:00 Lift Timing Chain Out
28:26 Reference Photographs
29:50 Credits
