NERF MOD: Nerf Rival Zeus HIRricane 1.0 Parts List and Breakdown

Full parts list and walkthrough of the Rival MXV 5600 mod.

FULL COMPONENT LIST: (UPDATED WITH NEW ELBOW LINK on McMaster)

Blower: https://www.sparkfun.com/products/11270

Tubing: 1.09” polycarbonate tubing: This is available at mcmaster as 2044T47 http://www.mcmaster.com/#catalog/121/..., but Tap Plastics has the same thing, though they are selling it as florescent tubing guards. You also CAN use 1” PVC and 1” elbows available at any home depot/lowes, but you have to do some sanding to get the elbow to fit in the bottom.

Elbows: 1" ID elbows : http://www.mcmaster.com/#catalog/121/... (PART # 5035K33 on McMaster)

T- Junction 1" CPVC T (couldn't find on McMaster):
http://www.homedepot.com/p/NIBCO-1-in...

Top end cap:
http://www.homedepot.com/p/NIBCO-1-in...

DC voltage boost circuit: http://www.amazon.com/gp/product/B00C...

Solenoid: http://www.amazon.com/gp/product/B008...

Acrylic cement:
http://www.amazon.com/SCIGRIP-10315-A...

16 Gauge hobby wire or hookup wire:
https://outofdarts.com/products/16-aw...

XT-60 connectors:
https://outofdarts.com/products/xt-60...

21A Microswitch (2x):
https://outofdarts.com/products/21a-m...

3 Cell Lipo (REQUIRED 3S to drive 12v blower):
https://outofdarts.com/products/zippy...

Other tools/supplies needed:
Hot Glue: Very handy for holding down wires in the frame.
Soldering iron/soldering station
