CHR Tower Speakers Part 2 | Best DIY Speaker Build 2022 | Markaudio CHR-90 + SB Acoustics Woofers

CHR TOWER PART 2

In this video I report the last steps to build the CHR Towers. Woodworking; measurements, cutting, gluing and finishing the boxes plus results, crossovers and frequency response curves.

The CHR Towers are a fantastic pair of powerful audio, low bass, high quality speakers. Made in Walnut Hardwood mixed with Euro-Ply and veneer, this design relies on the Markaudio CHR-90 Full-range and the SB Acoustics SB15MFC30-8 Woofer. This is a two way speaker box that impresses by its power, SPL and High Fidelity performance, even using 5" woofer drivers and full-ranges.


CHR TOWER PART 1 LINK

   • CHR Tower Speakers Part 1 | High Power | D...

CHR TOWER PART 3 LINK

   • Видео


MATERIALS

Walnut Hardwood, Walnut Veneer, Euro Plywood, Metal, Drivers, X-over Components, Connectors.

Walnut hardwood case with Plywood side baffles. Finished with Good Stuff wax. Steel Metal modern spike feet finished in matte black.


LINKS

Drivers:

Markaudio CHR-90 Full-range driver:
https://www.madisoundspeakerstore.com...

SB Acoustics SB15MFC30-8:
https://www.madisoundspeakerstore.com...

Crossover parts:

1.5 mH Inductor
https://www.parts-express.com/Dayton-...

15 uF Capacitor
https://www.parts-express.com/Solen-1...

47 uF Capacitor
https://www.parts-express.com/Solen-4...


Accessories:

Binding Posts:
https://amzn.to/3unCgdQ

4-Way Speaker Terminal:
https://amzn.to/3YYvpag

Speaker spike feet:
https://amzn.to/3F2UwOu

Sonic Barrier:
https://www.parts-express.com/Sonic-B...

Speaker Wire - Oxygen Free Copper:
https://amzn.to/39tNkPe


MEASUREMENTS

Speaker Outside - 93 x 35 x 17 cm
Closed Box Internal - 16 x 13 x 31 cm (6.5 Liters)
Vented Box Internal - 67 x 13 x 31 cm (27 Liters)
Port - 13 x 3 x 28

ATTENTION!!!

NEW CROSSOVER:

Full Range - 47 uF Capacitor in series
Woofers - 1.5mH Inductor in series / 15 uF Capacitor in parallel



BASIC TOOLS FOR WOODWORKING

Plam Sander: https://amzn.to/39wtgvy
Compressor: https://amzn.to/3wAxB90
Nail Gun: https://amzn.to/3LrlYqm
Circular Saw: https://amzn.to/3yNB7Ql
Drill Kit: https://amzn.to/39osBMR
Drill Bits: https://amzn.to/3llbApI
Screwdriver Bits: https://amzn.to/3MmMgLS
Router: https://amzn.to/3wyyHCb
Router Circle Jig: https://amzn.to/3MuZLcw
Router Bit Set: https://amzn.to/3FRFriK
Clamps: https://amzn.to/3FR9IhO
Quick Clamps: https://amzn.to/3FSRufH
Soldering Station: https://amzn.to/3PCFLXk

INSTAGRAM: @sonnoradesign
