RopeCAM 10.4

This video is about RopeCAM 10.4

RopeCAM produces NC-code for any outer or inner diameter rope thread, as well as others like trapezoid and buttress. It uses a number of threading cycles at different locations to rough and finish the thread using a standard turning tool instead of an expensive special custom tool.

All of the codes it uses are customizable for use with different controls. When programming taper for a thread, RopeCAM allows a descending slope for the thread profile. RopeCAM also applies for cable barrel thread NC-programming. Example: Rd DIN 405-1 thread can be machined with a standard turning tool.


Key features:
Rope thread NC-programming
Buttress thread NC-programming
More advanced thread profile follow up
Thread roughing uses stepover and stepdown values given by the user
More advanced thread profile simulation with zoom and speed control
Ability to measure the tool offset from the middle or from the corner
Ability to program the flat portion of the thread top
International regional settings
Trapezoid thread, acme thread NC-programming
Trapezoid thread, acme thread measurements table
Ability to add thread measurements and cutting parameters as comments in the NC-code
Theoretical Surface Roughness (Ra) calculation
Scallop height calculation
Buttress thread features (different side angles and radii)
Multi-start thread programming
Selection of thread profile machining direction (Z+/-)
Thread profile with rounded bottom
Q-type NC-code for Mori Seiki lathes
Project management, open, save, save as…
Variable pitch support for all thread types
Entry/Exit taper
NEW in version 10: Buttress thread with vertical flank (SIEMENS KUN 301.04 Standard)
