Delta PLC Analog Programe and I/O wiring in details 0-10Volt

#PLC_analog_input
In this video I have discussed about Delta PLC analog operation in detail

#automation_service_in_siliguri

he Analog Input Module (AIN) is a key subsystem in the PLC. AINs come in many variations to condition real world physical parameters, such as, Temperature, Pressure, Force, or Strain. Typically, these AIN inputs are command signals in both voltage (e.g. ±10V) and current form (e.g. 4-20mA).
contact - electrosoftautomata@gmail.com
#PLCanalog
#PLC_wearing
00:00 - materials details & configuration
00:50 - to show the exact value in the HMI I have made a HMI Program using Numeric Display
01:30 - Write ladder Programe for delta PLC Analog card - #DVP06XA-S
02:50 - Download raw Programe To the PLC for testing
03:00 - Scale the exact value of VOLTMeter using Division instruction
05:00 - Final result with 0-Volt to 10-Volt vareation using a POT
06:00 - Analog Wearing (#2-wear) For a Volt mitter Or Any Analog Device That is operating in 0-10Volt DC, like a load cell, Temperature Sensor etc.



Disclaimer :
All the software interfaces shown in the video are for educational purposes only, & this are downloded by the ENTERNET search. The look can vary/differ based on change in version but the process/ procedure/ steps more or less remains the same.
#INDUSTRIAL_AUTOMATION
#ElectroSoftAutomata

Note:
In case of any doubt, Kindly drop a comment so that i can reach you to solve your issues.

Also, Comment your interested topics which you feel i should make video on.
