How to Build: Arduino Bmp180 Pressure Temperature Altitude Meter with OLED Display

This video show how to build BMP180 Barometric Pressure & Temp Sensor with I2C OLED Display and Arduino Uno.
A 128X64 i2c Oled ssd1306 display is used to display the barometeric Pressure, temperature and altitude.
I used an Arduino UNO 3.3V clone.
BMP180 sensors are cheap and easily available on ebay, bangood, sparkfun etc.
Library used U8Glib: Installed directly from the Library Manager in Arduino IDE. Select version 1.18.0. For Some reason Version 1.19.0 update gave crc error.
The OLED display VCC is connected to 3.3V of Arduino. Gnd to Gnd of Arduino.
SDA of OLED to SDA or Arduino, SCL of OLED to SCL of Arduino.
Code: Copy and save with .ino extension.
http://www.jaimeferns.in/2016/10/ardu...
