Water level indicator and motor control || fully automated using Arduino|| ultrasonic sensor || LCD
Автор: Haj Jamal Faizal B
Загружено: 2018-06-08
Просмотров: 22453
Hello everyone, here the fully automated water level indicator and motor control with LCD interface.
I coded it for more than 6 hrs it have two modes measurement mode and control mode.
U can use it for any height of tank by encode Ur tank height using pontentiometer.u can change mode by using the pushbutton.
circuit design:
https://drive.google.com/file/d/1BVbS...
Here is the source code
https://drive.google.com/file/d/1zUHH...
Arduino Nano:
Nano Mini USB With the bootloader compatible for arduino Nano 3.0 controller CH340 USB driver 16Mhz Nano v3.0 ATMEGA328P
http://s.aliexpress.com/RfaQrmMb?from... to Clipboard
Ultrasonic sensor:HC-SR04 Ultrasonic Distance Measuring Sensor SR04 Module for arduino
http://s.aliexpress.com/RJvuQRZr?from... to Clipboard
relay module: https://rover.ebay.com/rover/0/0/0?mp...
