DIY $250 Electric Skateboard Cheap FAST Light

Build your own electric skateboard within an extremely competitive budget.

Durable containment | https://goo.gl/MLG6rM | $7.09

Battery | https://goo.gl/do37rd | $31.96

Motor Mount and Pulley Kit | https://goo.gl/2kPPMf | $19.69

*Used in this build, for dual motor* ESC/ Receiver/ Transmitter | https://goo.gl/7XNfyu | $62.00

*Another option, For single motor** ESC/ Receiver/ Transmitter | https://goo.gl/3imWLV | $43.80

Motor | https://goo.gl/vXgDp8 | $38.99

Wheels | https://goo.gl/jZiFc2 wheels | $22.99

LED Lights | https://goo.gl/rMzzYS | $11.95


****Total cost of this build WITH peripherals (assuming you already have a board)
$194.67

The board I use | https://goo.gl/3usqMm | $52.22

Bullet connectors - https://goo.gl/4o6anr

_________________________________________________________________________

Boosted Board (Commercial Electric Skateboard)
20 mph top speed | Range 7 miles | 15 pounds
Price- $1299

My DIY Board
17 mph top speed | Range 7 miles | 12 pounds
Price- $247

---------------------------------------------------------------------------------------

*****How to calculate your speed with NO LOAD (no rider on skateboard) with your motor's kv rating, battery voltage and wheels size. Assuming your belt system is a 1:3 reduction.

Formula:
[(Motor's kv X Applied Voltage X Wheel size in meters X Pi X 60 minutes) X 1/3 gear ratio] / 1000 (to change meters to kilometers) = Your speed in KM/H without load

Speed in KM/H X (0.62) = Speed in MPH

--------------------------------
Example:
[(400kv motor X 22 Volts X 0.076m wheel diameter X Pi X 60 minutes) X 1/3 gear ratio] / 1000 = 42. 02KM/H
42.02 KM/H X (0.62) = 26.05 MPH without load

17 mph with a 175 lbs rider
