How to shell parts in solidworks
Автор: Design Mountain
Загружено: 2021-07-23
Просмотров: 6048
How to shell parts in solidworks
In this video you will learn how to shell parts in solidworks.
We take an in depth look at the shell feature in solidworks along with the diagnostic tools that enable us to analyse a part to see if its geometry is suitable to shell.
We not only look at the shell feature and how to use it but also how you can modify part geometry to make it more suitable.
🔔 Subscribe and hit the bell to get notified about our weekly videos
/ designmountain
Timestamps:
0:00 how to shell parts in solidworks intro
0:50 shell feature
2:00 understand the feature
2:43 shell feature diagnostics
3:24 check feature / min radius of curvature
3:50 optimise geometry for shell
5:46 fillets
6:48 show preview
7:00 shell outward
7:12 multi-thickness
8:10 outro
