How to Connect up a Twin Socket Wired in PVC Single - Earthing the Metal Box - In Plastic Conduit

Electrician Matt shows you how to connect up (wire up) a metal clad twin socket outlet when it’s wired in 2.5mm squared PVC singles as an A3 radial wired through PVC conduit.

How to twist up PVC single insulated conductor correctly when wiring in a conduit system and the connect a twin socket outlet to them.

== 🕐 Time Stamps - Cut to the action 🕕 ==

00:00 - How to connect up a socket outlet
00:05 - Cut the loop
00:23 - Strip of the PVC on the conductors
00:54 - Twisting the conductors
01:12 - Nice twisted end
02:03 - All conductors twisted and ready for connecting
02:48 - Connecting the line conductors
03:39 - Connected socket outlet
04:15 - Fly lead to the back of the metal box

On socket outlets with 2 earth terminals connected to ring final circuit we like our learners at Tresham College to place one circuit CPC in each of the terminals and then a fly lead out of which ever earth terminal they like.

How to connect up a twin socket
How to make off a twin socket
How to connect up a twin socket
How to terminate a twin socket
How to connect up a BS 1363 socket outlet

NOTE: The video was cut short but Matt pushed the socket back into place and that check tighten all the terminals again before screwing the twin socket to the box.

🔵 How To Terminate (Connect Up) a Twin Socket Outlet BS 1363 (How to Wire a Double Socket)    • How To Terminate (Connect Up) a Twin Socke...

Videos are training aids for City and Guilds (C and G) and EAL courses Level 1, 2, 3 plus AM2, AM2S and AM2E.
