Non-Nulling Data Acquisition System

A Brief Look at the Non-Nulling Data Acquisition System A short video featuring Dr. Kevin Linfield, P.E.

Airflow Sciences recently finalized an SBIR project related to a novel flow measurement procedure. For the past several years, ASC has partnered with NIST to advance flow measurement procedures and technology. The Phase II SBIR project completion is an important step towards industry acceptance and commercialization of this new testing methodology.

The Fluid Metrology Group at NIST developed a non-nulling test procedure, which eliminates the need to rotate a 3D probe during a flow traverse. This change significantly reduces both the time to test a given traverse point and the potential for error due to inaccurate or inconsistent probe nulling techniques. Test personnel only need to insert the probe to the desired location and record the pressures from the sensing holes P1 to P5.

ASC was the recipient of two Phase I SBIR awards to develop a prototype non-nulling data acquisition system. The Non-Nulling Data Acquisition System implements the NIST methodology and achieves high accuracy flow measurement without needing to rotate or null the probe. ASC received a Phase II SBIR award to follow-up on this hardware development and optimize it for stack flow testing use.

A typical RATA test includes four test ports and ten traverse points per port, so test personnel must position the probes forty times for a single test run. The original test hardware prototype, developed during our Phase I project, was configured to measure pressures at one single test port, requiring the user to move the equipment around the stack and increasing the overall test duration.

The Phase II work that was just completed included the construction of additional measurement boxes, as well as the development of test software, which would allow a user to test on all four ports simultaneously.

This eliminates the need to move any measurement equipment around on the test platform, greatly reducing test time while also minimizing the chance of injury to test personnel.


For more information on field testing hardware, please contact Airflow Sciences. Thank you, and have a wonderful day.
