1 hp motor winding, 3 phase motor winding, electric motor winding, (PART 6) 36 slote, 1400 RPM

Thanks for watching this video. Please like & share the video.
Subscribe this channel for more videos.

PART 1 =    • 1 hp motor winding, 3 phase motor winding,...
PART 2 =    • 1 hp motor winding, 3 phase motor winding,...
PART 3 =    • 1 hp motor winding, 3 phase motor winding,...
PART 4 =    • 1 hp motor winding, 3 phase motor winding,...
PART 5 =    • 1 hp motor winding, 3 phase motor winding,...

Basic Motor Specs:
Power: 1 HP (approx. 0.75 kW)
Phases: 3 Phase
RPM: 1400 (indicates 4 poles)
Slots: 36
Frequency: 50 Hz
Voltage: 415V (typical for 3-phase motors)

Connection Details:
Star (Y) Connection: Used for reduced voltage starting and lower starting current.

Delta (Δ) Connection: Used for full voltage operation, providing higher torque.


Winding Procedure (Step-by-Step)
Mark all 36 slots and label them from 1 to 36.
Use enameled copper wire of proper gauge (typically 22–26 SWG for 1 HP).
Insert coils in double-layer format:
Coil 1: Top of Slot 1 → Bottom of Slot 9
Coil 2: Top of Slot 3 → Bottom of Slot 11
Continue until all coils are inserted.
Form 3 separate phase groups (U, V, W), each spaced 120° electrically
Join corresponding start or end wires according to star or delta diagram.
Insulate all joints properly and varnish the winding after testing.
