Designing a Discrete Half-bridge Gate Driver
Автор: Engineering Hustle
Загружено: 2023-09-22
Просмотров: 5795
Описание:
In this video I'm showing a discrete half-bridge gate driver design simulated in QSPICE.
You can find the QSPICE Simulation Files in the following github link: https://github.com/EngineeringHustle/...
Other QSPICE Design Videos:
• How to simulate an STM32 PWM in QSPICE usi...
• How to simulate an ADC in QSPICE using C++
• Simulating a Microcontroller PWM in C++ us...
Chapters:
0:00 Introduction
0:22 Why gate drivers?
1:04 Low-side gate driver
3:35 Bootstrap circuit
4:53 High-side gate driver
5:46 Conclusion
