Part 7: How to Design a Stable High Frequency Amplifier
Автор: Keysight Design Software
Загружено: 2020-03-17
Просмотров: 9605
Click this link https://www.keysight.com/find/eda-how... to request a .zip file that includes all of the analyses and more!
Link to the full series: • How to Design a Stable High Frequency Ampl...
This short video series introduces stability analysis in high frequency circuit design. Stability analysis is becoming much more critical in modern high frequency applications because gain and coupling cause new problems to arise that are not easy to resolve in the lab.
The seventh video complies the learnings from the previous vidoes to analyze two example high frequency amplifiers with the help of the WS-Probe. In the first example, probes are used to compute the
Normalized Determinant Function for a Class C Power Amplifier. In the second example, EM Circuit Excitation is used along with Keysight's RF Pro EM tool to track down feedback loops in a realistic Class AB Power Amplifier designed using a Qorvo GAN transistor and a Modelithics nonlinear device model.
To apply for free trial of ADS visit:
https://www.keysight.com/find/mytrial...
See also "Designing for Stability in High Frequency Circuits" application note at:
https://www.keysight.com/us/en/assets...
