DXF Import Options in FreeCAD (Applicable to DWG)

DXF import options in FreeCAD are explained in this video. The same options are valid for importing DWG file format.

There are multiple options which users can set during DXF import, such as whether layers should be imported, whether to import texts and dimensions, layouts or points. Users have also option to join layers into blocks and set usage of color during import. User also sets whether geometry should be imported as simple part shapes, draft objects or as sketches.

Viewers will also learn differences between the two importers – the new C++ DXF importer and the legacy Python DXF importer.

The practical example used in the video is a small architectural 2D plan view drawing.

---
Learn how to install DWG import and export for FreeCAD:    • Install DWG Import/Export for FreeCAD
Learn how to work with Layers in FreeCAD:    • FreeCAD Layers Overview


FreeCAD version used in the video: 1.0
DXF file icons created by rizal2109 – Flaticon: https://www.flaticon.com/free-icons/d...
Import icons created by Dixit Lakhani_02 – Flaticon: https://www.flaticon.com/free-icons/i...

Download FreeCAD from here: https://www.freecad.org/
Donate to the FreeCAD project: https://wiki.freecad.org/Donate

You can support the channel by donating either on Youtube or at Ko-Fi https://ko-fi.com/fcblounge
Follow FCB Lounge channel on LinkedIn:   / fcblounge
Follow FCB Lounge channel on BlueSky: https://bsky.app/profile/tomaspolak.b...

This video was created with the help of OBS: https://obsproject.com/
This video was created with the help of GIMP: https://www.gimp.org/
This video was created with the help of KDEnlive: https://kdenlive.org/

0:00 Introduction
2:40 Using default C++ DXF importer
22:36 Using legacy Python DXF importer
31:07 Conclusion
