Lithophane Creation | Vectric V11 Tutorials

This video demonstrates the techniques required to create lithophanes. We cover the best way to create a 3D model from an image and how to prepare the model for good results. We then calculate 3D roughing and finishing toolpaths and finally we demonstrate a useful method to determine the quality of the image on your lithophane before cutting it.

Bookmarks:
~ Introduction 00:15
~ Job setup 00:55
~ Importing a bitmap 01:58
~ Manipulating the bitmap 02:47
~ Deeper look at 3D view 04:37
~ Adjusting the combine mode for the model 05:07
~ Modelling plane overview 05:59
~ Adding a boundary vector 07:45
~ Toolpath setup 08:32
~ 3D roughing toolpath 10:10
~ 3D finishing toolpath 13:23
~ Lithophane preview options 15:22
~ Adding more detail to the finishing path 16:35
~ Saving the file and summary 19:32

To download the files used in this tutorial, view related videos or take advantage of our bookmarking system within the videos please head over to the support section of our website here: https://www.vectric.com/support/tutor...
