Convert ZWO MFW (Manual Filter Wheel) to ASCOM-Compliant EFW (Electronic!) for less than £17.00!
Автор: Michael Benn
Загружено: 2021-08-29
Просмотров: 1366
I thought I'd have a go at converting the ZWO 5-position manual filter wheel (MFW) into an ASCOM-compliant electronic filter wheel (EFW), which took a bit of fiddling, but now it's done :-)
The cost for the parts plus the £69 for the ZWO MFW comes to about £86 in all, and I have the satisfaction of knowing that I've made it myself too.
If anyone is interested in having a go, I'll upoad the 3D files, circuit diagram, circuit board layout and the software to Instructables or somewhere similar.
Also check out my neat Celestron auxilliary port splittter solution at the end, which allows the CGX mount to support the hand controller, the focus motor and the StarSense all at once, keeping the cabling really neat too. That's another saving, as the Celestron equivalent is £26, and mine cost me about £3.50 :-)
00:00 - Introduction
01:12 - Demonstration
02:01 - Statistics on display
02:48 - Taking it apart
03:32 - Tour of the internals
04:29 - Rear view
04:44 - Removing the EFW module
05:10 - Tour of the circuit board
05:44 - Boot and operation with the top off
08:02 - View into the workings
08:35 - MFW Dismantled showing magnet
09:33 - Fit and finsh
10:33 - Reindexing
11:47 - Circuit diagram
13:08 - Parts list and costs
14:45 - EFW in use on Celestron CGX & C925
15:15 - Home-made Aux Port splitter
Enjoy :-)
