Fusion Circular Pattern Workflow: Pattern Fillets and Chamfers the Smart Way

Learn how to use the Circular Pattern tool in Autodesk Fusion to quickly repeat cuts and features around an axis. In this tutorial, you’ll sketch a simple shape, extrude a cut through the body, then use Create Pattern - Circular Pattern to pattern the feature evenly around your model. You’ll also see why patterning features (instead of bodies) is often the best workflow, and how editing your timeline first (adding fillets and chamfers before the pattern) can save a ton of clicks while keeping everything parametric. Finally, we’ll edit the circular pattern to include additional features and show how a single change updates the entire pattern automatically.

Chapters

00:00 Circular Pattern overview in Autodesk Fusion
00:14 Sketch setup on the circular face
00:29 Construction line and constraints to the origin
00:42 Extrude cut settings (distance: All, operation: Cut)
00:55 Create Pattern - Circular Pattern command
01:08 Pattern type: Features, select the axis, set quantity
01:22 Resulting patterned cut and design variations
01:35 Add fillets before the pattern to avoid repetitive clicks
01:46 Add chamfers to top edges before patterning
02:09 Why the pattern only includes selected features
02:23 Edit circular pattern and add more features (Ctrl or Command select)
02:44 Parametric update demo by editing a feature dimension
02:56 Wrap-up: faster modeling with feature patterns

What you’ll learn

When to use Bodies vs Features in Circular Pattern
How to choose an axis and set pattern quantity
Timeline strategy: add fillets and chamfers before the pattern
How to edit a circular pattern to include additional features
How parametric updates propagate through the full pattern
