Part 5: Plan Development Workflow
Автор: FDOT Training
Загружено: 2019-10-09
Просмотров: 7014
Date: 10/2/2019
Presenter: Chris Thorp
Description: This webinar is part 5 of 10 and will cover Key Sheets, Plans Only Sheets, Plan and Profile Sheets and Cross Section Sheets.
Q&A: https://fdotwww.blob.core.windows.net...
Presentation: https://fdotwww.blob.core.windows.net...
Table of Contents:
00:00 - Intro
02:22 - Named Boundary Tool
04:18 - Review Ribbon Interface
05:33 - Key Sheet
06:14 - Plan Only Sheets
07:21 - Plan Over Profile Sheets
07:52 - Create Drawing Dialogue
08:17 - Cross Sections
09:10 - Create Sheet Files
10:22 - Key Sheet Demo
10:54 - Pop-up Menu "Space Bar"
11:15 - Attached PDF Map
13:08 - Named Boundary Tool - Demo
17:11 - Create Sheet Index with LDM
18:56 - Placing Active Cells
24:56 - Plan Sheet Demo
29:00 - Display Bugs
31:15 - Manipulate References
32:14 - Place Label Tool
34:23 - Plan and Profile Sheet Demo
36:32 - Offset Bug
41:56 - Plan/ Profile Sheet Bug
43:36 - Cross Section Demo
49:05 - End Area Volumns
51:00 - End Area Volumn Report
