Märklin Brake Module 72442/1 with Märklin 764xx Light/70xxx Semaphore Signals (Beginner Episode 12b)

This video describes how to connect the Märklin 72442/72441 braking module (aka brake module aka signal module) to a Märklin light or semaphore signal. This is a continuation of "Beginners Episode 12a" (   • Installing Märklin Brake Module 72442/7244...  ) that described how the brake module works, troubleshooting and Tips'n'Tricks.

In the video the Märklin 72442 brake module is used. However, you can use the Märklin 72441 brake module in the same way.

ALWAYS do the installation with POWER OFF, read the manual and safety instructions. Remember to connect the wires correctly to each section.

More Information / background videos
• Installing Märklin Brake Module 72442/72441 using M83 60832/60831 (Beginner Episode 12a):    • Installing Märklin Brake Module 72442/7244...

Tips & How to included:
• How to connect the brake module to a light signal
• How to connect the brake module to a semaphore signal
• How to insulate the transition, braking and stop section (Red/B/Center rail)
• Tip: Insulate the connector closest to the center rail on both tracks
• Tip: Power brake module and signal with power bus or outside sections
• Tip: You need a 16v AC power supply to power braking section
• Tip: You can use old Märklin power supplies (66471, 6647 or 600x)
• Tip: You can use Viessmann 5200 power supply or similar 16V AC
• How to connect the
• Tip: The brake module automatically brake the locomotive before the signal
• Tip: The locomotive has sound and light when stopped at the signal
• Tip: The locomotive continue when the signal turns green again
• Tip: The locomotive only brakes when the signal is stop/red
• Tip: The Märklin 72442 and 72441 are the same - just different connectors
• Tip: The locomotive must support the Märklin brake module
• Tip: Use the 3 wire (1 purple and 2 red) supplied with the signal
• Tip: The red/green wire is to the opposite side of the purple wire
• Tip: The red/brown wire is in the center of the plug
• Tip: Retrace all wires before testing to ensure you connected it correctly

Enjoy and have fun with model trains :-)

Interesting links (English):
Märklin: https://www.maerklin.de/en
Märklin 72442: https://www.maerklin.de/en/products/d...
Märklin 72441: https://www.maerklin.de/en/products/d...

Chapters
00:00 Intro
03:23 Brake module summary from Episode 12a
06:32 Märklin light signals supported
08:50 Märklin semaphore signals supported
09:49 Light signal connection diagram
14:45 Semaphore connection diagram
17:38 Brake module install
18:18 Insulating track sections
21:08 Brake module connection
24:05 Semaphore-brake module connection
30:00 Semaphore-power supply connection
32:28 Semaphore wire review
34:05 Semaphore testing (2 aspect signal)
36:32 Light signal-brake module connection
41:02 Light signal-power supply connection
43:02 Light signal wire review
44:10 Light signal testing (3 aspect signal)
47:39 Outro
