1) Taglio delle effe parte prima - Tracciatura della posizione degli occhi
Автор: Davide Sora
Загружено: 2017-08-04
Просмотров: 13704
Indice dei video : http://davidesora.altervista.org/video/
ENGLISH TRANSLATION of the written notes in the video, in order of appearance :
00:04 - Cutting of soundholes part one
Drawing the eyes position according to the Stradivari system
00:13 - This system allows you to locate the F-holes eyes center position in relation to the line of the ribs so as to keep the same distance from them on the left and right sides. It is not based on specific geometric proportions, but it is a simple system of transfer of measurements obtained with tries and adjustments based on the final desired position of the F-holes.
00:31 - The lower eyes should be tangent to the line passing through the lower margins of the purfling on the outside of the top plate and it will be enough to transfer the measures of the drawing as such.
00:42 - For the upper eyes, conversely, it is necessary to increase the measure of the drawing due to the inclination caused by the depth of the inside hollowing of the arching, which will vary depending on the height of the same, so as to achieve the desired distance between them, respecting their centering with the centerline of the plate.
Index of videos : http://davidesora.altervista.org/videos/
